10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car

Product Categories
Henan Remarkable Intelligent Technology Co., Ltd.
Contact Now

10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car

Brand Name : Remarkable

Model Number : RWP

Certification : CE, ISO

Place of Origin : Henan, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 600

Delivery Time : 30-45 work days

Packaging Details : 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.

Power supply : electric

Load : 3 tons

other name : trackless transfer wagon

Operation method : Wireless remote control & Hand operate pendant

Traveling speed（m/min） : 0-30 (Stepless speed regulation)

Brake mode : Electromagnetic brake

application area : tires transport

Move Way : Forward, backward, turning while driving with no stop

Contact Now

10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car

It is used in the fields of automobile production, ship manufacturing, die stamping, steel allocation, transportation and assembly of large machinery and equipment. It is used for cross transportation in multiple workshops. It is more convenient than rail flat car and can greatly increase work efficiency. The frame is made of steel plate, the electric flat car table can be laid with anti-skid rubber pad, and the running speed can be adjusted steplessly. Operating system: onboard handle + wireless remote control, table size can be customized according to customer requirements. The heavy trackless electric flat car can turn flexibly and has forward, backward, left and right buttons, speed regulation button, emergency stop button, abnormal light indication, power on light indication, authority key and other control buttons. With the advantages of simple operation, smooth turning and easy maintenance, trackless electric flat car will win the favor of many enterprises and manufacturers.10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car

10 Tons Wireless Electric Transfer Trolley , Stepless Speed Die Transfer Car

Technical parameters for electric transfer carts
1 rated load(t) 5 10 15 20 30 40 50 150
2 impacted rated load(t) 7.5 15 22.5 30 45 60 75 225
3 structure of frame steel plates welded, beam structure
4 max. wheel load(t) 2.8 4.3 4.8 5.6 7.7 10 12 27
5 ground requirement cement floor steel plate ground
6 table size(mm) 3000×2000 3600×2000 4000×2200 4500×2200 5000×2200 5500×2300

6000×

2300

10000×

3000
7 height of the whole cart(mm) 450 530 600 600 650 700 700 1200
8 ground clearance(mm) 50 75
9 wheels base(mm) 1500 1700 1800 2000
10 axles distance(mm) 2500 3100 3400 3900 4300 4800 5200 10000
11 turning radius(mm) 2501 3101 3401 3901 4301 4801 5201 10001
12 turning type turning while driving with no stop
13 control method for turning control button
14 turning structure mechanical
15 motor power(Kw) 3.5 5 6 7 10 12 15 15
16 wheel diameter(mm) Ф300 x 4 Ф350 x 4 Ф400 x 4 Ф400 x 6 Ф500 x 6 Ф600 x 8
21 battery model D-250 x 24 D-33 x 24 D-400 x 24 D-440 x 24 D-250 x 36 D-330 x 36 D-440 x 36 D-600 x 36
22 battery maintenance free of maintenance
23 charger's installation installed on cart split-type
24 charger function automatic charging
25 radar control 3-0.3m, automatic stop for obstacles
26 warning equipment sound and light
27 other functions turning light, night light and power display
